1518_pAAV-U6-SA-eGFP-gRNA-HLP-SACas9-HA-OLLAS-spA
(Plasmid #109316)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 109316 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pEMBL8
  • Backbone size w/o insert (bp) 6967
  • Total vector size (bp) 6966
  • Modifications to backbone
    SaCas9 was cloned from Addgene Plasmid #61593
  • Vector type
    Mammalian Expression, AAV, CRISPR

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    eGFP gRNA
  • gRNA/shRNA sequence
    GGGGTCTTTGCTCAGGGCGGA

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BbsI (destroyed during cloning)
  • 3′ cloning site BbsI (destroyed during cloning)
  • 5′ sequencing primer CCTTCATATTTGCATATACGATACAAGGCTGTTAG
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    1518_pAAV-U6-SA-eGFP-gRNA-HLP-SACas9-HA-OLLAS-spA was a gift from William Lagor (Addgene plasmid # 109316 ; http://n2t.net/addgene:109316 ; RRID:Addgene_109316)
  • For your References section:

    A Self-Deleting AAV-CRISPR System for In Vivo Genome Editing. Li A, Lee CM, Hurley AE, Jarrett KE, De Giorgi M, Lu W, Balderrama KS, Doerfler AM, Deshmukh H, Ray A, Bao G, Lagor WR. Mol Ther Methods Clin Dev. 2018 Dec 6;12:111-122. doi: 10.1016/j.omtm.2018.11.009. eCollection 2019 Mar 15. 10.1016/j.omtm.2018.11.009 PubMed 30619914
