KG#84
(Plasmid #110878)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 110878 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pUC
  • Backbone size w/o insert (bp) 2617
  • Total vector size (bp) 7957
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert 1

  • Gene/Insert name
    unc-17beta promoter
  • Species
    C. elegans (nematode)
  • Insert Size (bp)
    491

Cloning Information for Gene/Insert 1

Gene/Insert 2

  • Gene/Insert name
    acy-1 P260S gain-of-function cDNA
  • Species
    C. elegans (nematode)
  • Insert Size (bp)
    3762
  • Mutation
    Changed Proline to Serine at amino acid 260

Cloning Information for Gene/Insert 2

Gene/Insert 3

  • Gene/Insert name
    unc-54 3' control region with 1 artificial intron just upstream and 1 artificial intron in control region
  • Species
    C. elegans (nematode)
  • Insert Size (bp)
    978

Cloning Information for Gene/Insert 3

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Used Age I/ Xho I to cut out the 3800 bp acy-1(P260S) cDNA from KG#81 and cloned into the like-digested unc-17b expression vector KG#65 (4200 bp). Transformed into XL1-Blue electrocompetent cells. Miniprepped 4 clones to find one with correct size insert and vector and made glycerol stock. The insert was previously checked by sequencing and contains only the P260S mutation.

Features of the construct: This expression construct has a promoter (unc-17beta) that will drive strong expression of the acy-1(P260S) cDNA in the A and B classes of ventral cord motor neurons + AS's, but not VC's or cholinergic neurons in the head or tail. The vector contains a "decoy" (see 1995 vector kit documentation) upstream of the promoter to reduce background expression in the gut and pharynx from read-through transcription. An unc-54 3' end containing a poly A addition signal is downstream of the MCS to stop transcription and provide a 3' UTR for the transcript. Three introns in the UTR's are included to give stable and uniform expression (1 in the 5' UTR, 1 just upstream of the unc-54 3' end, and 1 in the unc-54 3' end sequence). This construct includes only the coding region. The sequence AAAA is engineered just after the 5' restriction site and just before the initiator ATG. An AT immediately follows the TAA stop codon for a consensus stop site. Note: the acy-1 cDNA from which this clone was produced corresponds to the single acy-1 cDNA predicted by wormbase, which is F17C8.1.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    KG#84 was a gift from Kenneth Miller (Addgene plasmid # 110878 ; http://n2t.net/addgene:110878 ; RRID:Addgene_110878)
  • For your References section:

    Mutations that rescue the paralysis of Caenorhabditis elegans ric-8 (synembryn) mutants activate the G alpha(s) pathway and define a third major branch of the synaptic signaling network. Schade MA, Reynolds NK, Dollins CM, Miller KG. Genetics. 2005 Feb;169(2):631-49. doi: 10.1534/genetics.104.032334. Epub 2004 Oct 16. 10.1534/genetics.104.032334 PubMed 15489510
