pJL1-aadA
(Plasmid #117050)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 117050 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pJL1
  • Backbone size w/o insert (bp) 1759
  • Total vector size (bp) 2554
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    aadA
  • Alt name
    streptomycin/spectinomycin resistance gene
  • Insert Size (bp)
    792
  • Promoter T7

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NdeI (not destroyed)
  • 3′ cloning site SalI (not destroyed)
  • 5′ sequencing primer TAATACGACTCACTATAGGG
  • 3′ sequencing primer TAGTTATTGCTCAGCGGTGG
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    EXPRESSYS pZS4Int-tetR

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pJL1-aadA was a gift from Michael Jewett (Addgene plasmid # 117050 ; http://n2t.net/addgene:117050 ; RRID:Addgene_117050)
  • For your References section:

    BioBits Health: Classroom Activities Exploring Engineering, Biology, and Human Health with Fluorescent Readouts. Stark JC, Huang A, Hsu KJ, Dubner RS, Forbrook J, Marshalla S, Rodriguez F, Washington M, Rybnicky GA, Nguyen PQ, Hasselbacher B, Jabri R, Kamran R, Koralewski V, Wightkin W, Martinez T, Jewett MC. ACS Synth Biol. 2019 May 7. doi: 10.1021/acssynbio.8b00381. 10.1021/acssynbio.8b00381 PubMed 30925042
