PurposeNme2Cas9 CMV-driven mammalian expression plasmid
-
Depositing Lab
-
Sequence Information
Ordering
| Item | Catalog # | Description | Quantity | Price (USD) | |
|---|---|---|---|---|---|
| Plasmid | 119923 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 | |
This material is available to academics and nonprofits only.
Backbone
-
Vector backbonepCDest
- Backbone size w/o insert (bp) 3300
- Total vector size (bp) 7600
-
Vector typeMammalian Expression
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberUnknown
Gene/Insert
-
Gene/Insert nameNme2Cas9
-
Alt nameNme2Cas9c
-
SpeciesN. meningitidis
-
Insert Size (bp)3300
- Promoter CMV
-
Tag
/ Fusion Protein
- NLS-3xHA-NLS (C terminal on insert)
Cloning Information
- Cloning method Gibson Cloning
- 5′ sequencing primer GGCACCGGCGGGCCCAAGAAGAA
- 3′ sequencing primer CATGGTGGCGCCAGCCTGCTTTTTTGTAC (Common Sequencing Primers)
Resource Information
-
Articles Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
How to cite this plasmid
( Back to top)
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
Nme2Cas9_pCDest was a gift from Erik Sontheimer (Addgene plasmid # 119923 ; http://n2t.net/addgene:119923 ; RRID:Addgene_119923) -
For your References section:
A Compact, High-Accuracy Cas9 with a Dinucleotide PAM for In Vivo Genome Editing. Edraki A, Mir A, Ibraheim R, Gainetdinov I, Yoon Y, Song CQ, Cao Y, Gallant J, Xue W, Rivera-Perez JA, Sontheimer EJ. Mol Cell. 2018 Dec 18. pii: S1097-2765(18)31033-5. doi: 10.1016/j.molcel.2018.12.003. 10.1016/j.molcel.2018.12.003 PubMed 30581144
