pLenti NLuc398-hLGALS8 IRES hCALCOCO2-CLuc394
(Plasmid #128387)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 128387 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pLV
  • Backbone manufacturer
    VectorBuilder
  • Backbone size w/o insert (bp) 7344
  • Total vector size (bp) 12269
  • Vector type
    Mammalian Expression, Lentiviral, Luciferase, Synthetic Biology
  • Selectable markers
    Blasticidin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    30°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    Unknown

Gene/Insert 1

  • Gene/Insert name
    NLuc398-3xGGGGS-LGALS8
  • Alt name
    Gal8
  • Alt name
    Galectin 8
  • Species
    H. sapiens (human), Synthetic
  • GenBank ID
    NM_201545.2
  • Entrez Gene
    LGALS8 (a.k.a. Gal-8, PCTA-1, PCTA1, Po66-CBP)
  • Promoter EFS
  • Tag / Fusion Protein
    • NLuc398 (N terminal on insert)

Cloning Information for Gene/Insert 1

Gene/Insert 2

  • Gene/Insert name
    CALCOCO2-3xGGGGS-CLuc394
  • Alt name
    CALCOCO2
  • Alt name
    NDP52
  • Species
    H. sapiens (human)
  • GenBank ID
    NM_001261390.1
  • Entrez Gene
    CALCOCO2 (a.k.a. NDP52)
  • Promoter IRES
  • Tag / Fusion Protein
    • CLuc394 (C terminal on insert)

Cloning Information for Gene/Insert 2

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    Outsourced synthesis

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pLenti NLuc398-hLGALS8 IRES hCALCOCO2-CLuc394 was a gift from Craig Duvall (Addgene plasmid # 128387 ; http://n2t.net/addgene:128387 ; RRID:Addgene_128387)
  • For your References section:

    Genetically encoded split-luciferase biosensors to measure endosome disruption rapidly in live cells. Kilchrist KV, Tierney JW, Duvall CL. ACS Sens. 2020 Jun 23. doi: 10.1021/acssensors.0c00103. 10.1021/acssensors.0c00103 PubMed 32573202
