pBPGUw
(Plasmid #17575)

Add to Cart
Available to Academic and Nonprofits Only

Backbone

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin and Chloramphenicol
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DB3.1
  • Growth instructions
    Bacterial Strain DB3.1 (Invitrogen) or similar must be used to propagate plasmids carrying the ccdB gene.
  • Copy number
    High Copy

Sequence Information

Full plasmid sequence is available only if provided by the depositing laboratory.

Gene/Insert

  • Gene/Insert name
    GAL4
  • Species
    S. cerevisiae (budding yeast)
  • Insert Size (bp)
    2646
  • Entrez Gene
    GAL4 (a.k.a. YPL248C, GAL81)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site KpnI (not destroyed)
  • 3′ cloning site NotI (not destroyed)
  • 5′ sequencing primer BDP F (bp 11,652): AAATAGGGGTTCCGCGCACAT
  • 3′ sequencing primer BDP R (bp 5,435) : ATAATGGTGCAGGGCGCTGAC
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    GAL4 leader, CDS, and hsp70 polyA were cloned from pGaTB (via DGRC).
  • Terms and Licenses

Depositor Comments

pBPGUw is a modular Gateway compatible GAL4 vector amenable to high throughput in vitro cloning using Invitrogen LR clonase and specific in vivo genomic targeting using PhiC31 integrase. pBPGUw contains a Drosophila synthetic core promoter (DSCP) that contains TATA, Inr, MTE, and DPE motifs. In addition the GAL4 CDS and yeast transcriptional terminator can easily be substituted for another driver by a directional 5' KpnI to 3' HindIII digest.

How to cite this plasmid

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pBPGUw was a gift from Gerald Rubin (Addgene plasmid # 17575)
  • For your References section:

    Tools for Neuroanatomy and Neurogenetics in Drosophila. Pfeiffer BD, Jenett A, Hammonds AS, Ngo TT, Misra S, Murphy C, Scully A, Carlson JW, Wan KH, Laverty TR, Mungall C, Svirskas R, Kadonaga JT, Doe CQ, Eisen MB, Celniker SE, Rubin GM.. Tools for neuroanatomy and neurogenetics in Drosophila 10.1073/pnas.0803697105 PubMed 18621688
