pASTA3
(Plasmid #24657)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 24657 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pSMT3-S
  • Backbone size w/o insert (bp) 5582
  • Vector type
    Bacterial Expression
  • Selectable markers
    Hygromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Hygromycin, 200 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    tdTomato
  • Species
    Synthetis gene
  • Insert Size (bp)
    1450

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BamHI (not destroyed)
  • 3′ cloning site HindIII (not destroyed)
  • 5′ sequencing primer M13rev
  • 3′ sequencing primer pBluescriptKS
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    Synthetic gene obtained from Jeff Cirillo
  • Articles Citing this Plasmid

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pASTA3 was a gift from Tanya Parish (Addgene plasmid # 24657 ; http://n2t.net/addgene:24657 ; RRID:Addgene_24657)
  • For your References section:

    Sensitive detection of gene expression in mycobacteria under replicating and non-replicating conditions using optimized far-red reporters. Carroll P, Schreuder LJ, Muwanguzi-Karugaba J, Wiles S, Robertson BD, Ripoll J, Ward TH, Bancroft GJ, Schaible UE, Parish T. PLoS One. 2010 . 5(3):e9823. 10.1371/journal.pone.0009823 PubMed 20352111
