pF150 pSOD1G93AAcGFP1
(Plasmid #26411)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 26411 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pAcGFP1-N1
  • Backbone manufacturer
    Clontech
  • Backbone size w/o insert (bp) 4700
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    SOD1
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    470
  • Mutation
    G94A
  • Entrez Gene
    SOD1 (a.k.a. ALS, ALS1, HEL-S-44, IPOA, SOD, STAHP, hSod1, homodimer)
  • Tag / Fusion Protein
    • GFP (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site EcoRI (not destroyed)
  • 3′ cloning site SalI (not destroyed)
  • 5′ sequencing primer CMV-F
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    human cDNA insert from cDNA clone cSOD1 from Professor Yoram Groner as described in Lieman-Hurwitzet al., 1982 and Sherman et al 1983.
  • Articles Citing this Plasmid

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

The complete cDNA was subcloned into the vector pET28. Site directed mutagenesis changed wildtype DNA sequence for codon 93 of the cDNA from GGT to GCT, resulting in the G93A mutation in the protein and then a PCR amplified the complete cDNA with EcoRI and SalI sites on the 5’ and 3’ end respectively. This EcoRI-Sal1 0.47kb fragment was cloned into the respective EcoRI and SalI sites of pAcGFP1N1. Thus SOD1 is 5’ of GFP and SOD1 lies upstream of GFP in the SOD1-GFP fusion protein.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pF150 pSOD1G93AAcGFP1 was a gift from Elizabeth Fisher (Addgene plasmid # 26411 ; http://n2t.net/addgene:26411 ; RRID:Addgene_26411)
  • For your References section:

    Modification of superoxide dismutase 1 (SOD1) properties by a GFP tag--implications for research into amyotrophic lateral sclerosis (ALS). Stevens JC, Chia R, Hendriks WT, Bros-Facer V, van Minnen J, Martin JE, Jackson GS, Greensmith L, Schiavo G, Fisher EM. PLoS One. 2010 . 5(3):e9541. 10.1371/journal.pone.0009541 PubMed 20221404
