pAtLCYbSK
(Plasmid #53588)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 53588 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pBluescript SK-
  • Backbone manufacturer
    Stratagene
  • Backbone size w/o insert (bp) 2958
  • Total vector size (bp) 4748
  • Modifications to backbone
    The entire open reading frame of an Arabidopsis lcyB cDNA [GenBank U50739.1] in plasmid pZL1 (the original cDNA library plasmid) was excised as an EcoRI-HindIII fragment of ca. 1.8 kB and cloned in the same sites of pBluescript SK- so that the cDNA was fused, in frame, to the N terminal portion of the lacZ gene and under the control of the lac promoter.
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    XL1 Blue
  • Growth instructions
    Can be used with pAC-LYC or pAC-LYCipi to produce beta-carotene in E. coli strain TOP10. For this purpose, grow liquid cultures on a platform shaker at 28 degrees Celsius for 2-3 days in darkness, or grow on agar plates at room temperature for 3-7 days.
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    lcyB
  • Alt name
    lycopene beta-cyclase
  • Species
    A. thaliana (mustard weed)
  • Insert Size (bp)
    1946
  • GenBank ID
    U50739.1
  • Entrez Gene
    LYC (a.k.a. AT3G10230, LYCOPENE BETA-CYCLASE, lycopene cyclase)
  • Promoter lac

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site EcoRI (not destroyed)
  • 3′ cloning site HindIII (not destroyed)
  • 5′ sequencing primer none
  • 3′ sequencing primer none
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pAtLCYbSK was a gift from Francis X Cunningham Jr (Addgene plasmid # 53588 ; http://n2t.net/addgene:53588 ; RRID:Addgene_53588)
  • For your References section:

    Carotenoid biosynthesis in the primitive red alga Cyanidioschyzon merolae. Cunningham FX Jr, Lee H, Gantt E. Eukaryot Cell. 2007 Mar;6(3):533-45. Epub 2006 Nov 3. 10.1128/EC.00265-06 PubMed 17085635
