pMXs-puro-RFP-ATG9A
(Plasmid #60609)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 60609 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pMXs-puro
  • Backbone manufacturer
    Dr.Toshio Kitamura of the University of Tokyo
  • Backbone size w/o insert (bp) 6878
  • Vector type
    Mammalian Expression, Retroviral
  • Selectable markers
    Puromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Homo sapiens autophagy related 9A
  • Alt name
    ATG9
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    2520
  • GenBank ID
    NM024085
  • Entrez Gene
    PPARG (a.k.a. CIMT1, GLM1, NR1C3, PPARG1, PPARG2, PPARG5, PPARgamma)
  • Tag / Fusion Protein
    • RFP (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site EcoRI (unknown if destroyed)
  • 3′ cloning site EcoRI (unknown if destroyed)
  • 5′ sequencing primer gggaattccATGGCGCAGTTTGACACTGA
  • 3′ sequencing primer gggaattcTCTATACCTTGTGCACCTGAGG
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

The S592G and H669N mutations found in Addgene's QC results are natural variants (SNP)

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pMXs-puro-RFP-ATG9A was a gift from Noboru Mizushima (Addgene plasmid # 60609 ; http://n2t.net/addgene:60609 ; RRID:Addgene_60609)
  • For your References section:

    Temporal analysis of recruitment of mammalian ATG proteins to the autophagosome formation site. Koyama-Honda I, Itakura E, Fujiwara TK, Mizushima N. Autophagy. 2013 Oct;9(10):1491-9. doi: 10.4161/auto.25529. Epub 2013 Jul 10. 10.4161/auto.25529 PubMed 23884233
