pCH194
(Plasmid #72317)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 72317 Standard format: Plasmid sent in bacteria as agar stab 1 $65

This material is available to academics and nonprofits only.

Backbone

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin
  • Growth Temperature
    37°C
  • Growth Strain(s)
    XL1 Blue
  • Growth instructions
    Show YFP fluo. when IPTG added or no LacI existing.
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    modified YFP
  • Species
    Synthetic
  • Insert Size (bp)
    717
  • GenBank ID
  • Promoter Prhl/lac-s

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site same to CH8 (unknown if destroyed)
  • 3′ cloning site same to CH8 (unknown if destroyed)
  • 5′ sequencing primer same to CH8
  • 3′ sequencing primer same to CH8
  • (Common Sequencing Primers)

Resource Information

Depositor Comments

T203Y mutant from sfGFP

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pCH194 was a gift from Matthew Bennett (Addgene plasmid # 72317 ; http://n2t.net/addgene:72317 ; RRID:Addgene_72317)
  • For your References section:

    SYNTHETIC BIOLOGY. Emergent genetic oscillations in a synthetic microbial consortium. Chen Y, Kim JK, Hirning AJ, Josic K, Bennett MR. Science. 2015 Aug 28;349(6251):986-9. doi: 10.1126/science.aaa3794. 10.1126/science.aaa3794 PubMed 26315440
