(Plasmid #86779)


Item Catalog # Description Quantity Price (USD)
Plasmid 86779 Standard format: Plasmid sent in bacteria as agar stab 1 $65

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone manufacturer
    Hahn et al., 2017
  • Backbone size w/o insert (bp) 14121
  • Total vector size (bp) 14834
  • Modifications to backbone
    Introduction of U6-26p::sgRNA
  • Vector type
    Plant Expression, Synthetic Biology
  • Selectable markers

Growth in Bacteria

  • Bacterial Resistance(s)
  • Growth Temperature
  • Growth Strain(s)
    NEB Stable
  • Copy number


  • Gene/Insert name
    sgRNA against GLABROUS1
  • Species
  • Insert Size (bp)
  • Promoter Arabidopsis U6-26 promoter

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer gtaaaacgacggccag
  • 3′ sequencing primer TATTACTGACTCGTCGGGTA
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    Peter Hegemann (HU Berlin)
  • Terms and Licenses

Depositor Comments

Generates mutations in GLABROUS1 gene, resulting in trichomeless Arabidopsis leaf phenotype (see Hahn et al., 2017)

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    [email protected] was a gift from Andreas Weber (Addgene plasmid # 86779 ; ; RRID:Addgene_86779)
  • For your References section:

    An Efficient Visual Screen for CRISPR/Cas9 Activity in Arabidopsis thaliana. Hahn F, Mantegazza O, Greiner A, Hegemann P, Eisenhut M, Weber AP. Front Plant Sci. 2017 Jan 24;8:39. doi: 10.3389/fpls.2017.00039. eCollection 2017. 10.3389/fpls.2017.00039 PubMed 28174584
