mCherry-CRY2clust
(Plasmid #105624)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 105624 Standard format: Plasmid sent in bacteria as agar stab 1 $94
Add to Cart
DNA 105624-D50 50 μg of DNA in Tris buffer $495
Add to Cart
DNA 105624-D100 100 μg of DNA in Tris buffer $585
Add to Cart

Backbone

  • Vector backbone
    pmCherry-C1
  • Backbone manufacturer
    Clontech
  • Backbone size w/o insert (bp) 4658
  • Total vector size (bp) 6179
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    mCherry-CRY2PHR-9aa
  • Alt name
    mCherry-CRY2clust
  • Alt name
    839529
  • Species
    H. sapiens (human), A. thaliana (mustard weed)
  • Insert Size (bp)
    1521
  • Entrez Gene
    CRY2 (a.k.a. AT1G04400, AT-PHH1, ATCRY2, CRYPTOCHROME 2 APOPROTEIN, F19P19.14, F19P19_14, FHA, PHH1, cryptochrome 2)
  • Promoter CMV
  • Tag / Fusion Protein
    • 9 amino acids (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BsrGI (not destroyed)
  • 3′ cloning site MfeI (not destroyed)
  • 5′ sequencing primer ATGAAGATGGACAAAAAGACCATCGTCTGG
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Trademarks:

  • Zeocin® is an InvivoGen trademark.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 50 μg
  • Concentration 1 μg/μL
  • Pricing $495 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 100 μg
  • Concentration 1 μg/μL
  • Pricing $585 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    mCherry-CRY2clust was a gift from Won Do Heo (Addgene plasmid # 105624 ; http://n2t.net/addgene:105624 ; RRID:Addgene_105624)

  • For your References section:

    Optogenetic protein clustering through fluorescent protein tagging and extension of CRY2. Park H, Kim NY, Lee S, Kim N, Kim J, Heo WD. Nat Commun. 2017 Jun 23;8(1):30. doi: 10.1038/s41467-017-00060-2. 10.1038/s41467-017-00060-2 PubMed 28646204
