pU6-(BsaI)_CBh-UC-Cas9-T2A-mCherry
(Plasmid #135014)

• Purpose: Expression vector for sgRNAs cloned into the BsaI sites and for expression of Cas9 with 126aa MRN-recruiting domain from HSV-1 UL12 fused to C-terminus of Cas9, linked to mCherry via a T2A peptide
• Depositing Lab: Yosef Shaul
• Depositing Organization: Weizmann Institute of Science
  Located in Israel
• Publication: Reuven et al Biomolecules. 2019 Oct 8;9(10). pii: biom9100584. doi: 10.3390/biom9100584.
• Citations: 1 Article

Backbone

• Vector backbone: pU6-(BbsI)_CBh-Cas9-T2A-mCherry (Addgene 64324), modification of pX330 (Addgene 42230)
• Backbone manufacturer: Kuehn lab
• Total vector size (bp): 9663
• Modifications to backbone: Sites for cloning sgRNAs changed to BsaI. Sticky ends for cloning sgRNAs are the same as the original parent vectors. 126aa domain from HSV-1 UL12 fused to C-terminus of Flag-Cas9, upstream of the T2A-mCherry
• Vector type: Mammalian Expression

Growth in Bacteria

• Bacterial Resistance(s): Ampicillin, 100 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): NEB Stable
• Copy number: High Copy

Gene/Insert

• Gene/Insert name: humanized S. pyogenes Cas9
• Alt name: SpCas9
• Alt name: hSpCas9
• Species: humanized S. pyogenes
• Insert Size (bp): 4272
• Mutation: 126aa domain from HSV-1 UL12 fused to the C-terminus of Flag-Cas9, upstream of the T2A-mCherry
• Promoter: CBh
• Tags / Fusion Proteins:
  • 3xFLAG (N terminal on insert) (N terminal on insert)
  • 3x Flag (N terminal on insert)
  • NLS (N terminal on insert)
  • NLS (C terminal on insert)
  • T2A-mCherry (C terminal on insert)

Cloning Information

• Cloning method: Restriction Enzyme
• 5′ cloning site: FseI (not destroyed)
• 3′ cloning site: HindIII (not destroyed)
• 5′ sequencing primer: GCTGGACGCCACCCTGATC

Resource Information

• A portion of this plasmid was derived from a plasmid made by: The UL12 fragment was pcr amplified from the pSAK UL12/12.5 plasmid from Sandra K. Weller's laboratory, University of Connecticut Health Center

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry

DNA (Catalog # 135014-D50)

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

• Amount: 50 μg
• Concentration: 1 μg/μL
• Pricing: $495 USD
• Storage: 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

DNA (Catalog # 135014-D100)

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

• Amount: 100 μg
• Concentration: 1 μg/μL
• Pricing: $585 USD
• Storage: 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.
