(Plasmid #188035)


Item Catalog # Description Quantity Price (USD)
Plasmid 188035 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone size w/o insert (bp) 5000
  • Total vector size (bp) 6354
  • Vector type

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
  • Growth Strain(s)
    NEB Stable
  • Copy number


  • Gene/Insert name
  • Alt name
    Calcium permeable Channelrhodopsin 2
  • Species
    Synthetic; Chloromonas oogama
  • Insert Size (bp)
  • Mutation
    S43D, L112C, T139C and N238E mutations in CoChR
  • Promoter hSyn
  • Tag / Fusion Protein
    • eYFP (C terminal on insert)

Cloning Information

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pAAV-Syn_CapChR2_eYFP was a gift from Peter Hegemann (Addgene plasmid # 188035 ; ; RRID:Addgene_188035)
  • For your References section:

    Calcium-permeable channelrhodopsins for the photocontrol of calcium signalling. Fernandez Lahore RG, Pampaloni NP, Peter E, Heim MM, Tillert L, Vierock J, Oppermann J, Walther J, Schmitz D, Owald D, Plested AJR, Rost BR, Hegemann P. Nat Commun. 2022 Dec 21;13(1):7844. doi: 10.1038/s41467-022-35373-4. 10.1038/s41467-022-35373-4 PubMed 36543773
