JZ005_Fsyn_Voltron2_ST_P2A_Cheriff_EGFP_ST
(Plasmid #258171)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 258171 Standard format: Plasmid sent in bacteria as agar stab 1 $94
Add to Cart

Backbone

  • Vector backbone
    pLenti
  • Vector type
    Lentiviral

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    30°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    Voltron2_ST_P2A_Cheriff_EGFP_ST
  • Species
    Synthetic
  • Promoter hSyn

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer aggcttgaccgacaattgcat
  • 3′ sequencing primer atcgataagcttgatatcgaattcttagaatctgg
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Trademarks:

  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Please visit https://doi.org/10.64898/2026.07.17.739178 for bioRxiv preprint.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    JZ005_Fsyn_Voltron2_ST_P2A_Cheriff_EGFP_ST was a gift from Adam Cohen (Addgene plasmid # 258171 ; http://n2t.net/addgene:258171 ; RRID:Addgene_258171)

  • For your References section:

    Absolute voltage mapping using dynamic photocycle control. Gong D, Zhang J, Howell MR, Wu X, Jia BZ, Cohen AE. bioRxiv 2026.07.17.739178 10.64898/2026.07.17.739178
