(Plasmid #61709)


Item Catalog # Description Quantity Price (USD)
Plasmid 61709 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Vector type
    Yeast Expression
  • Selectable markers

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
  • Growth Strain(s)
    XL1 Blue
  • Copy number
    High Copy


  • Gene/Insert name
  • Alt name
  • Species
    S. cerevisiae (budding yeast)
  • Insert Size (bp)
  • Mutation
    Heteromeric coiled coil inserted after amino acid 678; A595C*
  • Entrez Gene
    HSP82 (a.k.a. YPL240C, HSP90)
  • Promoter GPD1
  • Tag / Fusion Protein
    • 6xHis (N terminal on insert)

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer cagctatgaccatgattacg
  • 3′ sequencing primer gtaaaacgacggccagtgagc
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

*Note: This plasmid contains an A595C amino acid residue substitution. This residue change does not alter Hsp90 function in yeast but enables cross-dimer disulfide formation under oxidizing conditions. This construct accurately represents the plasmid as it was used in the associated publication.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    p414GPD_Hsp82viiB was a gift from Dan Bolon (Addgene plasmid # 61709 ; ; RRID:Addgene_61709)
  • For your References section:

    Designed Hsp90 heterodimers reveal an asymmetric ATPase-driven mechanism in vivo. Mishra P, Bolon DN. Mol Cell. 2014 Jan 23;53(2):344-50. doi: 10.1016/j.molcel.2013.12.024. 10.1016/j.molcel.2013.12.024 PubMed 24462207
