PurposeMoClo golden gate assembly BC part for BCD20 (Medium expression bi-cistronic RBS, engineered for downstream context-independence; see https://doi.org/10.1038/nmeth.2404).
|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||121019||Standard format: Plasmid sent in bacteria as agar stab||1||$75|
This material is available to academics and nonprofits only.
- Backbone size w/o insert (bp) 2100
Vector typeSynthetic Biology
Growth in Bacteria
Copy numberHigh Copy
Insert Size (bp)92
- Cloning method Gibson Cloning
- 5′ sequencing primer AAATAGGCGTATCACGAGGCA
- 3′ sequencing primer TTACCGCCTTTGAGTGAGCTG (Common Sequencing Primers)
Recombines readily with other BCD sequences Please see Supplemental Documents for annotated Genbank file.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:U6m was a gift from Richard Murray (Addgene plasmid # 121019 ; http://n2t.net/addgene:121019 ; RRID:Addgene_121019)
