pMXs-hSTING-GFP
(Plasmid #185442)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 185442 Standard format: Plasmid sent in bacteria as agar stab 1 $94

Backbone

  • Vector backbone
    pMXs-IRES-Blasticidin Retroviral Vector
  • Backbone manufacturer
    Cell BioLabs
  • Backbone size w/o insert (bp) 5644
  • Total vector size (bp) 7531
  • Vector type
    Retroviral
  • Selectable markers
    Blasticidin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    Stimulator of Interferon Genes
  • Alt name
    STING1, TMEM173
  • Species
    H. sapiens (human), Synthetic
  • Insert Size (bp)
    1887
  • Entrez Gene
    STING1 (a.k.a. ERIS, MITA, MPYS, NET23, SAVI, STING, STING-beta, TMEM173, hMITA, hSTING)
  • Tag / Fusion Protein
    • GFP (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site Xho1 (not destroyed)
  • 3′ cloning site Not1 (not destroyed)
  • 5′ sequencing primer CATCGCAGCTTGGATACACGCC
  • 3′ sequencing primer EGFP-C-REV
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    Original STING1 insert obtained from Plasmid #124262

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Trademarks:

  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pMXs-hSTING-GFP was a gift from Pietro De Camilli (Addgene plasmid # 185442)
