C5V
(Plasmid #26394)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 26394 Standard format: Plasmid sent in bacteria as agar stab 1 $75

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pEGFP C1
  • Backbone size w/o insert (bp) 3984
  • Vector type
    Mammalian Expression ; FRET standard
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Cerulean-5-Venus
  • Alt name
    C5V
  • Insert Size (bp)
    1435
  • Tags / Fusion Proteins
    • Cerulean (N terminal on insert)
    • Venus (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site Nhe 1 (not destroyed)
  • 3′ cloning site Bam HI (not destroyed)
  • 5′ sequencing primer CCAAAATCAACGGGACTTTCC
  • 3′ sequencing primer CAGGTTCAGGGGGAGGTGTGG
  • (Common Sequencing Primers)

Resource Information

Depositor Comments

FRET standard

This construct contains Cerulean attached via a 5 amino acid linker to Venus. See supplemental methods section in associated paper for further details on plasmid construction.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    C5V was a gift from Steven Vogel (Addgene plasmid # 26394 ; http://n2t.net/addgene:26394 ; RRID:Addgene_26394)
  • For your References section:

    Cerulean, Venus, and VenusY67C FRET reference standards. Koushik SV, Chen H, Thaler C, Puhl HL, Vogel SS. Biophys J. 2006 Dec 15. 91(12):L99-L101. 10.1529/biophysj.106.096206 PubMed 17040988
