(Plasmid #31302)

Add to Cart
Available to Academic and Nonprofits Only


  • Vector backbone
  • Backbone manufacturer
  • Backbone size w/o insert (bp) 5137
  • Vector type
    Mammalian Expression
  • Selectable markers

Growth in Bacteria

  • Bacterial Resistance(s)
  • Growth Temperature
  • Growth Strain(s)
  • Copy number
    High Copy

Sequence Information


  • Gene/Insert name
    green fluorescent protein
  • Alt name
  • Insert Size (bp)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site HindIII (not destroyed)
  • 3′ cloning site XhoI (not destroyed)
  • 5′ sequencing primer na
  • (Common Sequencing Primers)

Resource Information

Depositor Comments

for Flp mediated site directed integration, tetracycline inducibility

How to cite this plasmid

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    FR_GFP was a gift from Gerhart Ryffel (Addgene plasmid # 31302)
  • For your References section:

    Tissue-specific transcription factor HNF4alpha inhibits cell proliferation and induces apoptosis in the pancreatic INS-1 beta-cell line. Erdmann S, Senkel S, Arndt T, Lucas B, Lausen J, Klein-Hitpass L, Ryffel GU, Thomas H. Biol Chem. 2007 Jan . 388(1):91-106. 10.1515/BC.2007.011 PubMed 17214554
