pWPI-myogenin
(Plasmid #79073)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 79073 Standard format: Plasmid sent in bacteria as agar stab 1 $65

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pWPI
  • Backbone size w/o insert (bp) 11001
  • Total vector size (bp) 11804
  • Vector type
    Lentiviral

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin
  • Growth Temperature
    30°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    human myogenin
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    672
  • Entrez Gene
    MYOG (a.k.a. MYF4, bHLHc3, myf-4)
  • Promoter EF1 alpha

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site AscI (unknown if destroyed)
  • 3′ cloning site NdeI (unknown if destroyed)
  • 5′ sequencing primer pWPI upstream primer
  • 3′ sequencing primer pWPI downstream primer
  • (Common Sequencing Primers)

Resource Information

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pWPI-myogenin was a gift from Jennifer Lei (Addgene plasmid # 79073)
