Rtn3LΔ6LIR-mNeonGreen
(Plasmid #169036)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 169036 Standard format: Plasmid sent in bacteria as agar stab 1 $94
Add to Cart
DNA 169036-D50 50 μg of DNA in Tris buffer $495
Add to Cart
DNA 169036-D100 100 μg of DNA in Tris buffer $585
Add to Cart

Backbone

  • Vector backbone
    mNeonGreen-N1
  • Backbone manufacturer
    Allele Biotechnology
  • Backbone size w/o insert (bp) 4700
  • Total vector size (bp) 8269
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Rtn3L
  • Alt name
    Rtn3b
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    3040
  • Mutation
    Changed following LC3-interacting regions of Rtn3L-mNeonGreen: FTLL, YSKV, FEVI, WDLV, FEEL, and YDIL to ATLA, ASKA, AEVA, ADLA, AEEA, and ADIA.
  • GenBank ID
    NM_201428.3
  • Entrez Gene
    RTN3 (a.k.a. ASYIP, HAP, NSPL2, NSPLII, RTN3-A1)
  • Promoter CMV
  • Tag / Fusion Protein
    • mNeonGreen (C terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site XhoI (not destroyed)
  • 3′ cloning site BamHI (not destroyed)
  • 5′ sequencing primer CGCAAATGGGCGGTAGGCGTG
  • 3′ sequencing primer CAAATGTGGTATGGCTGATT
  • (Common Sequencing Primers)

Terms and Licenses

Trademarks:

  • Zeocin® is an InvivoGen trademark.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 50 μg
  • Concentration 1 μg/μL
  • Pricing $495 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 100 μg
  • Concentration 1 μg/μL
  • Pricing $585 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Rtn3LΔ6LIR-mNeonGreen was a gift from Gia Voeltz (Addgene plasmid # 169036 ; http://n2t.net/addgene:169036 ; RRID:Addgene_169036)

  • For your References section:

    Reticulon-3 Promotes Endosome Maturation at ER Membrane Contact Sites. Wu H, Voeltz GK. Dev Cell. 2021 Jan 11;56(1):52-66.e7. doi: 10.1016/j.devcel.2020.12.014. 10.1016/j.devcel.2020.12.014 PubMed 33434526
