PurposeNT-CRISPR plasmid for a single gRNA with spG Cas9 (near PAM-less Cas9 variant).
-
Depositing Lab
-
Depositing OrganizationPhilipps-Universitaet Marburg
Located in Germany -
Citations
-
Sequence Information
Ordering
| Item | Catalog # | Description | Quantity | Price (USD) | |
|---|---|---|---|---|---|
| Plasmid | 179334 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $94 | |
| DNA | 179334-D50 | 50 μg of DNA in Tris buffer | $495 | ||
| DNA | 179334-D100 | 100 μg of DNA in Tris buffer | $585 | ||
Backbone
-
Vector backboneCustom built using Marburg Collection
-
Vector typeCRISPR
Growth in Bacteria
-
Bacterial Resistance(s)Chloramphenicol, 25 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert namePtac tfoX, Ptet spG cas9, PJ23106 acrIIA4, Ptet gRNA with sfGFP dropout
-
SpeciesE. coli, V. cholerae, S. pyogenes, Bacteriophage, A. victoria
-
MutationCas9 -> SpG Cas9 (D1135L, S1136W, G1218K, E1219Q, R1335Q, T1337R)
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site unknown (unknown if destroyed)
Resource Information
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Please visit https://www.biorxiv.org/content/10.1101/2021.08.02.454823v1 for bioRxiv preprint.
DNA (Catalog # 179334-D50)
Purpose
Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.
Delivery
- Amount 50 μg
- Concentration 1 μg/μL
- Pricing $495 USD
- Storage 4 ℃ (short-term) or -20 ℃ (long-term)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Quality Control
Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.
Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.
DNA (Catalog # 179334-D100)
Purpose
Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.
Delivery
- Amount 100 μg
- Concentration 1 μg/μL
- Pricing $585 USD
- Storage 4 ℃ (short-term) or -20 ℃ (long-term)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Quality Control
Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.
Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pST_140_LVL2 cam was a gift from Anke Becker (Addgene plasmid # 179334 ; http://n2t.net/addgene:179334 ; RRID:Addgene_179334) -
For your References section:
NT-CRISPR, combining natural transformation and CRISPR-Cas9 counterselection for markerless and scarless genome editing in Vibrio natriegens. Stukenberg D, Hoff J, Faber A, Becker A. Commun Biol. 2022 Mar 25;5(1):265. doi: 10.1038/s42003-022-03150-0. 10.1038/s42003-022-03150-0 PubMed 35338236
