pCI-neo-(HA)3-ε
(Plasmid #198531)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 198531 Standard format: Plasmid sent in bacteria as agar stab 1 $94
Add to Cart
DNA 198531-D50 50 μg of DNA in Tris buffer $495
Add to Cart
DNA 198531-D100 100 μg of DNA in Tris buffer $585
Add to Cart

Backbone

  • Vector backbone
    pCI-neo
  • Backbone size w/o insert (bp) 5474
  • Total vector size (bp) 8971
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    AP-4 ε
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    3522
  • Mutation
    silent substitutions in codons 235, 262, 905 and 1129
  • Entrez Gene
    AP4E1 (a.k.a. CPSQ4, SPG51, STUT1)
  • Promoter CMV
  • Tag / Fusion Protein
    • triple HA tag (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site XhoI (not destroyed)
  • 3′ cloning site SalI (not destroyed)
  • 5′ sequencing primer pCI-neo forward: 5’ CTCTCCACAGGTGTCCACTCCCAGTTC
  • 3′ sequencing primer pCI-neo reverse: 5’ CACTGCATTCTAGTTGTGGTTTGTCCAAACTCATC
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Trademarks:

  • Zeocin® is an InvivoGen trademark.

Depositor Comments

triple HA tag subcloned between XhoI and EcoRI sites, AP-4 ε subcloned betwen EcoRI and SalI sites; all sites are intact

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 50 μg
  • Concentration 1 μg/μL
  • Pricing $495 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 100 μg
  • Concentration 1 μg/μL
  • Pricing $585 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pCI-neo-(HA)3-ε was a gift from Juan Bonifacino (Addgene plasmid # 198531 ; http://n2t.net/addgene:198531 ; RRID:Addgene_198531)

  • For your References section:

    AP-4 mediates export of ATG9A from the trans-Golgi network to promote autophagosome formation. Mattera R, Park SY, De Pace R, Guardia CM, Bonifacino JS. Proc Natl Acad Sci U S A. 2017 Dec 12;114(50):E10697-E10706. doi: 10.1073/pnas.1717327114. Epub 2017 Nov 27. 10.1073/pnas.1717327114 PubMed 29180427
