pcDNA3.1(-)-C2C1-ErNaR-TS-EYFP-ES
(Plasmid #209851)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 209851 Standard format: Plasmid sent in bacteria as agar stab 1 $94
Add to Cart
DNA 209851-D50 50 μg of DNA in Tris buffer $495
Add to Cart
DNA 209851-D100 100 μg of DNA in Tris buffer $585
Add to Cart

Backbone

  • Vector backbone
    pcDNA3.1(-)
  • Backbone size w/o insert (bp) 5409
  • Total vector size (bp) 7212
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    light-driven sodium pump ErNaR
  • Alt name
    ErNaR
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1803
  • Promoter CMV
  • Tag / Fusion Protein
    • EYFP

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BamHI (not destroyed)
  • 3′ cloning site HindIII (not destroyed)
  • 5′ sequencing primer CMV-F
  • 3′ sequencing primer bGH polyA-R
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Trademarks:

  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Please visit https://doi.org/10.1101/2023.10.11.561842 for bioRxiv preprint.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 50 μg
  • Concentration 1 μg/μL
  • Pricing $495 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 100 μg
  • Concentration 1 μg/μL
  • Pricing $585 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pcDNA3.1(-)-C2C1-ErNaR-TS-EYFP-ES was a gift from Volker Busskamp (Addgene plasmid # 209851 ; http://n2t.net/addgene:209851 ; RRID:Addgene_209851)

  • For your References section:

    A subgroup of light-driven sodium pumps with an additional Schiff base counterion. Podoliak E, Lamm GHU, Marin E, Schellbach AV, Fedotov DA, Stetsenko A, Asido M, Maliar N, Bourenkov G, Balandin T, Baeken C, Astashkin R, Schneider TR, Bateman A, Wachtveitl J, Schapiro I, Busskamp V, Guskov A, Gordeliy V, Alekseev A, Kovalev K. Nat Commun. 2024 Apr 10;15(1):3119. doi: 10.1038/s41467-024-47469-0. 10.1038/s41467-024-47469-0 PubMed 38600129
