pFB-EF1a-DIO-GW1-PercevalHR-WPRE
(Plasmid #245383)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 245383 Standard format: Plasmid sent in bacteria as agar stab 1 $94
Add to Cart

Backbone

  • Vector backbone
    pFB
  • Backbone manufacturer
    Virovek
  • Backbone size w/o insert (bp) 4533
  • Total vector size (bp) 9170
  • Vector type
    Mammalian Expression, AAV

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    PercevalHR
  • Species
    Synthetic
  • Insert Size (bp)
    4637
  • Promoter EF1a

Cloning Information

  • Cloning method Unknown
  • 5′ sequencing primer TCAAGCCTCAGACAGTGGTTC
  • 3′ sequencing primer CCAGCTTGGTTCCCAATAGA
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Trademarks:

  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Please note that Addgene's sequencing results differ from the partial sequence information provided by the depositing laboratory, finding F54_M55insTA in the insert ORF compared to the partial reference sequence. The depositor confirms that this change is not known to affect plasmid function.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pFB-EF1a-DIO-GW1-PercevalHR-WPRE was a gift from D. James Surmeier (Addgene plasmid # 245383 ; http://n2t.net/addgene:245383 ; RRID:Addgene_245383)

  • For your References section:

    Feed-forward metabotropic signaling by Cav1 Ca(2+) channels supports pacemaking in pedunculopontine cholinergic neurons. Tubert C, Zampese E, Pancani T, Tkatch T, Surmeier DJ. Neurobiol Dis. 2023 Nov;188:106328. doi: 10.1016/j.nbd.2023.106328. Epub 2023 Oct 16. 10.1016/j.nbd.2023.106328 PubMed 37852390
