pENN.AAV.CAG.Flex.CaMPARI.WPRE.SV40
(Plasmid
#100831)
-
PurposeAAV expression of CaMPARI, a photoconvertible fluorescent protein-based calcium integrator
-
Depositing Labs
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 100831 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $75 | |
AAV5 | 100831-AAV5 | Virus (100 µL at titer ≥ 7×10¹² vg/mL) |
This material is available to academics and nonprofits only.
Backbone
-
Vector backbonepAAV
-
Vector typeMammalian Expression, AAV
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin
-
Growth Temperature37°C
-
Growth Strain(s)NEB Stable
-
Copy numberUnknown
Gene/Insert
-
Gene/Insert nameCaMPARI
-
SpeciesSynthetic
-
Insert Size (bp)1308
- Promoter CAG
Cloning Information
- Cloning method Unknown
- 5′ sequencing primer unknown (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
This plasmid was previously available as pENN.AAV.CAG.Flex.CaMPARI.WPRE.SV40 (p4090) from the Penn Vector Core.
Information for AAV5 (Catalog # 100831-AAV5) ( Back to top )
Addgene no longer distributes this item. Contact [email protected] for more information.
Virus (100 µL at titer ≥ 7×10¹² vg/mL)
Purpose
Ready-to-use AAV5 particles produced from pENN.AAV.CAG.Flex.CaMPARI.WPRE.SV40 (#100831). In addition to the viral particles, you will also receive purified pENN.AAV.CAG.Flex.CaMPARI.WPRE.SV40 plasmid DNA.
CAG-driven, Cre-dependent, photoconvertible (irreversible green-to-red) calcium integrator. These AAV preparations are suitable purity for injection into animals.Delivery
- Volume 100 µL
- Titer ≥ 7×10¹² vg/mL
- Pricing $350 USD for preparation of 100 µL virus + $30 USD for plasmid.
- Storage Store at -80℃. Thaw just before use and keep on ice.
- Shipment Viral particles are shipped frozen on dry ice. Plasmid DNA (≥ 200ng) will also be included in the shipment.
Viral Production & Use
- Packaging Plasmids encode adenoviral helper sequences and AAV rep gene, AAV5 cap gene
- Buffer PBS + 0.001% Pluronic F-68
- Serotype AAV5
- Purification Iodixanol gradient ultracentrifugation
Biosafety
Requestor is responsible for compliance with their institution's biosafety regulations. Lentivirus is generally considered BSL-2. AAV is generally considered BSL-1, but may require BSL-2 handling depending on the insert. Biosafety Guide
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Viral Quality Control
- Addgene ensures high quality viral vectors by optimizing and standardizing production protocols and performing rigorous quality control (QC) (see a list of our QC assays). The specific QC assays performed varies for each viral lot. To learn which specific QC assays were performed on your lot, please contact us.
- Titer: the exact titer of your sample will be reported on the tube. The titer you see listed on this page is the guaranteed minimum titer. See how titers are measured.
Visit our viral production page for more information.
Addgene Comments
Using FLEX vectors in vivo: LoxP sites in FLEX plasmids are known to recombine during DNA amplification and viral vector production, which may result in a minority of Cre-activated (i.e., "flipped") viral vectors. Addgene has measured this occurs in 0.1-0.8% of viral particles in our typical production protocol. This can lead to a small number of cells exhibiting Cre-independent transgene expression in vivo. To address this, it is necessary to optimize the injection volume and viral titer to find the optimal AAV dosage required for Cre-dependent transgene expression and function in vivo. This may include reducing the viral particle dosage in order to reduce the likelihood of Cre-independent expression.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pENN.AAV.CAG.Flex.CaMPARI.WPRE.SV40 was a gift from Loren Looger & Eric Schreiter (Addgene plasmid # 100831 ; http://n2t.net/addgene:100831 ; RRID:Addgene_100831)
For viral preps, please replace (Addgene plasmid # 100831) in the above sentence with: (Addgene viral prep # 100831-AAV5)
-
For your References section:
Neural circuits. Labeling of active neural circuits in vivo with designed calcium integrators. Fosque BF, Sun Y, Dana H, Yang CT, Ohyama T, Tadross MR, Patel R, Zlatic M, Kim DS, Ahrens MB, Jayaraman V, Looger LL, Schreiter ER. Science. 2015 Feb 13;347(6223):755-60. doi: 10.1126/science.1260922. 10.1126/science.1260922 PubMed 25678659
