|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||10808||Standard format: Plasmid sent in bacteria as agar stab||1||$75|
This material is available to academics and nonprofits only.
- Backbone size w/o insert (bp) 5446
Vector typeMammalian Expression
Selectable markersNeomycin (select with G418)
Growth in Bacteria
Bacterial Resistance(s)Ampicillin, 100 μg/mL
Copy numberHigh Copy
SpeciesH. sapiens (human)
Insert Size (bp)2800
Entrez GenePRKD1 (a.k.a. CHDED, PKC-MU, PKCM, PKD, PRKCM)
- Promoter CMV
/ Fusion Protein
- HA (N terminal on insert)
- Cloning method Restriction Enzyme
- 5′ cloning site BamHI (not destroyed)
- 3′ cloning site XhoI (not destroyed)
- 5′ sequencing primer CMV-F
- 3′ sequencing primer BGH-rev (Common Sequencing Primers)
Terms and Licenses
- Not Available to Industry
- Zeocin® is an InvivoGen trademark.
The HA tag on this plasmid contains a point mutation that renders it unrecognizable by the 3F10 HA antibody. It will work fine with the 12CA5 HA antibody.
The PKD insert in this plasmid contains a L520P mutation when compared to GenBank reference sequence NP_002733.1. Although the effect of this mutation is unknown, this is the exact plasmid used in the associated publication and it should function as described.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:HA.PKD was a gift from Alex Toker (Addgene plasmid # 10808 ; http://n2t.net/addgene:10808 ; RRID:Addgene_10808)
For your References section:Protein kinase D mediates a stress-induced NF-kappaB activation and survival pathway. Storz P, Toker A. EMBO J. 2003 Jan 2. 22(1):109-20. 10.1093/emboj/cdg009 PubMed 12505989
