pCW-eGFP-SHLD1
(Plasmid #114116)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 114116 Standard format: Plasmid sent in bacteria as agar stab 1 $65

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pCW57.1
  • Backbone manufacturer
    Addgene #41393
  • Backbone size w/o insert (bp) 7720
  • Total vector size (bp) 9061
  • Vector type
    Mammalian Expression, Lentiviral ; Doxycycline inducible
  • Selectable markers
    Puromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin
  • Growth Temperature
    30°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    SHLD1
  • Alt name
    C20orf196
  • Alt name
    RINN3
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1341
  • GenBank ID
  • Entrez Gene
    SHLD1 (a.k.a. C20orf196, RINN3)
  • Promoter TRE promoter, Tet ON
  • Tag / Fusion Protein
    • eGFP (N terminal on insert)

Cloning Information

  • Cloning method Gateway Cloning
  • 5′ sequencing primer LNCX
  • 3′ sequencing primer O.PGK1b-R (GAACGGACGTGAAGAATGTG)
  • (Common Sequencing Primers)

Resource Information

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pCW-eGFP-SHLD1 was a gift from Daniel Durocher (Addgene plasmid # 114116 ; http://n2t.net/addgene:114116 ; RRID:Addgene_114116)
  • For your References section:

    The shieldin complex mediates 53BP1-dependent DNA repair. Noordermeer SM, Adam S, Setiaputra D, Barazas M, Pettitt SJ, Ling AK, Olivieri M, Alvarez-Quilon A, Moatti N, Zimmermann M, Annunziato S, Krastev DB, Song F, Brandsma I, Frankum J, Brough R, Sherker A, Landry S, Szilard RK, Munro MM, McEwan A, Goullet de Rugy T, Lin ZY, Hart T, Moffat J, Gingras AC, Martin A, van Attikum H, Jonkers J, Lord CJ, Rottenberg S, Durocher D. Nature. 2018 Aug;560(7716):117-121. doi: 10.1038/s41586-018-0340-7. Epub 2018 Jul 18. 10.1038/s41586-018-0340-7 PubMed 30022168
