(Plasmid #117686)


Item Catalog # Description Quantity Price (USD)
Plasmid 117686 Standard format: Plasmid sent in bacteria as agar stab 1 $75

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone manufacturer
    Feng Zhang Lab
  • Backbone size w/o insert (bp) 9175
  • Total vector size (bp) 9175
  • Modifications to backbone
    K (AAG) 848 A (GCC), K (AAG) 1003 A (GCG), R (CGG) 1060 A (GCG)
  • Vector type
    Mammalian Expression, CRISPR
  • Selectable markers

Growth in Bacteria

  • Bacterial Resistance(s)
  • Growth Temperature
  • Growth Strain(s)
  • Copy number


  • Gene/Insert name
  • Alt name
    K848A, K1003A, R1060A
  • Species
  • Mutation
    K848A, K1003A, R1060A
  • Promoter U6

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site ApaI (not destroyed)
  • 3′ cloning site BsmI (not destroyed)
  • 5′ sequencing primer ACCCATTCCTGAAGGACAAC
  • 3′ sequencing primer TGGCCAGGTACAGGAAGTTC
  • (Common Sequencing Primers)

Resource Information

Depositor Comments

Created by Yang LIU and Luc LEYNS ([email protected]) from the Vrije Universiteit Brussel (Belgium).

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    eSpCas9(1.1)-Puro was a gift from Luc Leyns (Addgene plasmid # 117686 ; ; RRID:Addgene_117686)
  • For your References section:

    Loss of Emp2 compromises cardiogenic differentiation in mouse embryonic stem cells. Liu Y, Dakou E, Meng Y, Leyns L. Biochem Biophys Res Commun. 2019 Feb 14. pii: S0006-291X(19)30235-9. doi: 10.1016/j.bbrc.2019.02.048. 10.1016/j.bbrc.2019.02.048 PubMed 30773261
