PurposeDonor for precise CRISPR directed genomic integration using the GeneWeld method
|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||117779||Standard format: Plasmid sent in bacteria as agar stab||1||$75|
This material is available to academics and nonprofits only.
Backbone manufacturerKarl J. Clark
- Backbone size w/o insert (bp) 2856
Vector typeSynthetic Biology
Growth in Bacteria
Growth Strain(s)NEB Stable
Copy numberHigh Copy
SpeciesD. rerio (zebrafish)
Insert Size (bp)4088
- Cloning method Gibson Cloning
- 5′ sequencing primer aaaagcaagaaagaaaactagagtgg
- 3′ sequencing primer atggctcataacaccccttg (Common Sequencing Primers)
Terms and Licenses
- Not Available to Industry
- Zeocin® is an InvivoGen trademark.
Secondary gene is a gamma-crystalin promoter driving NLS-eGFP. Online tools and cloning help available at <www.genesculpt.org/gtaghd/>. gal4-VP16 should be used in conjunction with a UAS expression line. May work in additional species beyond those listed. Please note that some discrepancies were found between Addgene's quality control result and the depositor's provided sequence. The depositor noted that these discrepancies do NOT affect plasmid function.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:pPRISM-gal4-VP16-gcry-eGFP was a gift from Jeffrey Essner (Addgene plasmid # 117779 ; http://n2t.net/addgene:117779 ; RRID:Addgene_117779)
For your References section:Efficient targeted integration directed by short homology in zebrafish and mammalian cells. Wierson WA, Welker JM, Almeida MP, Mann CM, Webster DA, Torrie ME, Weiss TJ, Kambakam S, Vollbrecht MK, Lan M, McKeighan KC, Levey J, Ming Z, Wehmeier A, Mikelson CS, Haltom JA, Kwan KM, Chien CB, Balciunas D, Ekker SC, Clark KJ, Webber BR, Moriarity BS, Solin SL, Carlson DF, Dobbs DL, McGrail M, Essner J. Elife. 2020 May 15;9. pii: 53968. doi: 10.7554/eLife.53968. 10.7554/eLife.53968 PubMed 32412410
