pLEX-FHH-MTOR HEAT
(Plasmid #120709)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 120709 Standard format: Plasmid sent in bacteria as agar stab 1 $75

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pLEX
  • Backbone manufacturer
    Thermo Scientific
  • Backbone size w/o insert (bp) 10778
  • Total vector size (bp) 11958
  • Vector type
    Mammalian Expression, Lentiviral
  • Selectable markers
    Puromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    MTOR HEAT 1-9
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1230
  • Mutation
    Amino acids 1-409
  • Entrez Gene
    MTOR (a.k.a. FRAP, FRAP1, FRAP2, RAFT1, RAPT1, SKS)
  • Promoter CMV
  • Tag / Fusion Protein
    • Flag-HA-6xHIS (N terminal on backbone)

Cloning Information

  • Cloning method Ligation Independent Cloning
  • 5′ sequencing primer CACCAAAATCAACGGGACTT
  • 3′ sequencing primer ATATAGACAAACGCACACCGGCCT
  • (Common Sequencing Primers)

Resource Information

  • Supplemental Documents
  • A portion of this plasmid was derived from a plasmid made by
    pcDNA3-Flag mTOR wt (Addgene; Cat# 26603)

Terms and Licenses

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pLEX-FHH-MTOR HEAT was a gift from Paul Khavari (Addgene plasmid # 120709 ; http://n2t.net/addgene:120709 ; RRID:Addgene_120709)
  • For your References section:

    The Functional Proximal Proteome of Oncogenic Ras Includes mTORC2. Kovalski JR, Bhaduri A, Zehnder AM, Neela PH, Che Y, Wozniak GG, Khavari PA. Mol Cell. 2019 Jan 4. pii: S1097-2765(18)31031-1. doi: 10.1016/j.molcel.2018.12.001. 10.1016/j.molcel.2018.12.001 PubMed 30639242
