pNIC28-Bsa4
(Plasmid #26103)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 26103 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pET28a
  • Backbone manufacturer
    Novagen
  • Backbone size (bp) 5353
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    None
  • GenBank ID
    EF198106
  • Tag / Fusion Protein
    • His - TEV (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site Ligation-Independent cloning (destroyed during cloning)
  • 3′ cloning site Ligation-Independent cloning (destroyed during cloning)
  • 5′ sequencing primer T7F
  • 3′ sequencing primer T7R
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Primers for LIC cloning:

Upstream: add TACTTCCAATCCATG to the 5’ end (ATG in-frame with the desired coding
sequence).

Downstream: add TATCCACCTTTACTG to 5’ end of downstream primer; add termination
codon, if necessary.

Detailed cloning method available in the paper (Savitsky et al., J Struct Biol., 2010)

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pNIC28-Bsa4 was a gift from Opher Gileadi (Addgene plasmid # 26103 ; http://n2t.net/addgene:26103 ; RRID:Addgene_26103)
  • For your References section:

    High-throughput production of human proteins for crystallization: The SGC experience. Savitsky P, Bray J, Cooper CD, Marsden BD, Mahajan P, Burgess-Brown NA, Gileadi O. J Struct Biol. 2010 Jun 10. ():. 10.1016/j.jsb.2010.06.008 PubMed 20541610
