Addgene

478 p5Efli1ep
(Plasmid #31160)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 31160 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    p5E
  • Backbone size w/o insert (bp) 2810
  • Vector type
    Entry vector

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    chimeric fli1ep enhancer/promoter fragment

Cloning Information

  • Cloning method Gateway Cloning
  • 5′ cloning site Gateway (not destroyed)
  • 3′ cloning site Gateway (not destroyed)
  • 5′ sequencing primer M13pUC-fwd
  • 3′ sequencing primer M13rev
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

"p5E" refers to 5' entry clones flanked by L4-R1.

Drives endothelial expression.

See publication for more details: Dev Dyn. 2007 Nov . 236(11):3077-87 PMID: 17948311 https://www.ncbi.nlm.nih.gov/pubmed/17948311

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    478 p5Efli1ep was a gift from Nathan Lawson (Addgene plasmid # 31160 ; http://n2t.net/addgene:31160 ; RRID:Addgene_31160)
  • For your References section:

    Gateway compatible vectors for analysis of gene function in the zebrafish. Villefranc JA, Amigo J, Lawson ND. Dev Dyn. 2007 Nov . 236(11):3077-87. 10.1002/dvdy.21354 PubMed 17948311
