(Plasmid #32414)


Item Catalog # Description Quantity Price (USD)
Plasmid 32414 Plasmid sent as bacteria in agar stab 1 $65

This material is available to academics and nonprofits only.


  • Vector backbone
    pDONR221 P5-P2
  • Backbone manufacturer
  • Vector type
    Gateway cloning vector

Growth in Bacteria

  • Bacterial Resistance(s)
  • Growth Temperature
  • Growth Strain(s)
  • Copy number
    High Copy


  • Gene/Insert name
  • Alt name
    optimised version of WPRE
  • Mutation
    WPRE with deletion of X protein promoter and mutation of all four ATGs which are followed by an ORF encoding more than 25 amino acids

Cloning Information

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    pMP71 GFP oPRE Provided by Dr Axel Schambach the user of the oPRE should cite the original article describing the element by Axel Schambach of Hannover Biomedical Research School
  • Terms and Licenses
  • Article Citing this Plasmid

Depositor Comments

Gene Therapy (2006) 13, 641–645. doi:10.1038/; published online 15 December 2005

'Woodchuck hepatitis virus post-transcriptional regulatory element deleted from X protein and promoter sequences enhances retroviral vector titer and expression. Schambach A, Bohne J, Baum C, Hermann FG, Egerer L, von Laer D, Giroglou T. Gene Ther. 2006 Apr;13(7):641-5.'

Addgene Sanger sequencing confirms that all four ATGs in the oPRE have been mutated to TAGs

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pENTR-L5-oPRE-L2 was a gift from Matthew Nolan (Addgene plasmid # 32414)
  • For your References section:

    A Molecular Toolbox for Rapid Generation of Viral Vectors to Up- or Down-Regulate Neuronal Gene Expression in vivo. White MD, Milne RV, Nolan MF. Front Mol Neurosci. 2011;4:8. Epub 2011 Jul 4. 10.3389/fnmol.2011.00008 PubMed 21772812
