AAV-EF1a-DIO-ChIEF(E162A/T198C)-P2A-dTomato-WPRE-BGHpA
(Plasmid #51095)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 51095 Plasmid sent as bacteria in agar stab 1 $65

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pAAV-EF1a-DIO-WPRE-BGHpA
  • Backbone manufacturer
    custom
  • Backbone size w/o insert (bp) 1047
  • Total vector size (bp) 7137
  • Modifications to backbone
    Altered cloning sites and replaced HGHpA with smaller BGHpA
  • Vector type
    Mammalian Expression, AAV

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin
  • Growth Temperature
    37°C
  • Growth Strain(s)
    Stbl3
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    ChIEF(E162A/T198C)
  • Alt name
    ChIEFac
  • Species
    Synthetic
  • Insert Size (bp)
    1085
  • Mutation
    E162A/T198C
  • Promoter EF1a
  • Tag / Fusion Protein
    • P2A-dTomato (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site HpaI (not destroyed)
  • 3′ cloning site NheI (not destroyed)
  • 5′ sequencing primer gccagcttggcacttgatgtaattctcc
  • 3′ sequencing primer CCATACGGGAAGCAATAGCATG
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    The original ChIEF portion was obtained from Roger Tsien (UCSD/HHMI) through 3rd party Ed Boyden (MIT). The Boyden construct containing ChIEF has a 10 aa truncation at the C terminus of ChIEF compared to the original ref sequence but was tested and confirmed as functional in the Boyden lab.
  • Terms and Licenses

Depositor Comments

The addition of the E162A and T198C mutations in ChIEF impart higher photocurrent amplitude while retaining fast kinetic properties. This variant is proposed as an alternative to ChETA variants that exhibit smaller photocurrents and more toxicity.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    AAV-EF1a-DIO-ChIEF(E162A/T198C)-P2A-dTomato-WPRE-BGHpA was a gift from Jonathan Ting (Addgene plasmid # 51095)
