PurposePlasmid encoding tRNA-SupD for serine amber suppression. *Update: Please use the updated version, Plasmid 198598: SupD v2, which is more stable.
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 68307 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepKD
-
Modifications to backbonepKD is derived from pKK223-3 (Pharmacia). This plasmid encodes a serine amber suppressor tRNA. Another plasmid encoding a protein of interest with TAG at the proper position is needed for recombinant protein expression. See article and supplementary information for cloning information.
-
Vector typeBacterial Expression, Synthetic Biology
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)Top10
-
Copy numberUnknown
Gene/Insert
-
Gene/Insert name2xtRNA-SupD
Resource Information
-
Articles Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
See supplementary information accompanying article for additional cloning information. We recommend introducing this plasmid into a recoded strain of E. coli (no genomic TAG codons) for high-efficiency phoshoprotein expression.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
SupD was a gift from Jesse Rinehart (Addgene plasmid # 68307) -
For your References section:
A flexible codon in genomically recoded Escherichia coli permits programmable protein phosphorylation. Pirman NL, Barber KW, Aerni HR, Ma NJ, Haimovich AD, Rogulina S, Isaacs FJ, Rinehart J. Nat Commun. 2015 Sep 9;6:8130. doi: 10.1038/ncomms9130. 10.1038/ncomms9130 PubMed 26350500
