Fuw-dCas9-Dnmt3a_IM
(Plasmid #84478)

• Purpose: Lentiviral construct to express dCas9 fused with an inactive Dnmt3a catalytic domain (E664A, E756A)
• Depositing Lab: Rudolf Jaenisch
• Publication: Liu et al Cell. 2016 Sep 22;167(1):233-247.e17. doi: 10.1016/j.cell.2016.08.056.

Ordering

Item	Catalog #	Description	Quantity	Price (USD)
Plasmid	84478	Standard format: Plasmid sent in bacteria as agar stab	1	$75	Add to Cart
Lentiviral Prep	84478-LV	This item has been discontinued.	1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30	$130	Discontinued
Concentrated Lentiviral Prep	84478-LVC	This item has been discontinued.	1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30	$180	Discontinued

This material is available to academics and nonprofits only.

Backbone

• Vector backbone: FUW
  (Search Vector Database)
• Backbone size w/o insert (bp): 9207
• Total vector size (bp): 14313
• Vector type: Mammalian Expression, Lentiviral
• Selectable markers: Zeocin ; Resistance marker is outside the LTRs and will not be packaged into virus

Growth in Bacteria

• Bacterial Resistance(s): Ampicillin
• Growth Temperature: 37°C
• Growth Strain(s): NEB Stable
• Copy number: High Copy

Gene/Insert

• Gene/Insert name: dCas9-Dnmt3a_IM
• Species: H. sapiens (human), Synthetic
• Insert Size (bp): 5106

Cloning Information

• Cloning method: Restriction Enzyme
• 5′ cloning site: AscI (not destroyed)
• 3′ cloning site: EcoRI (not destroyed)
• 5′ sequencing primer: aactatgcgctcggg
• 3′ sequencing primer: taaagcagcgtatcc

Resource Information

• Terms and Licenses:
  • UBMTA
• Industry Terms:
  • Not Available to Industry

Information for Lentiviral Prep (Catalog # 84478-LV)

Item is discontinued.

Addgene no longer distributes this item. Contact for more information.

This item has been discontinued.

Purpose

Ready-to-use Lentiviral Prep particles produced from Fuw-dCas9-Dnmt3a_IM (#84478). In addition to the viral particles, you will also receive purified Fuw-dCas9-Dnmt3a_IM plasmid DNA.

Lentiviral particles carrying dCas9 fused with an inactive Dnmt3a catalytic domain (E664A, E756A)

Delivery

• Volume: .
• Titer: ≥5x10⁵ TU/mL
• Pricing: $100 USD for preparation of . virus + $30 USD for plasmid.
• Storage: Store at -80℃. Thaw just before use and keep on ice.
• Shipment: Viral particles are shipped frozen on dry ice. Plasmid DNA (≥ 200ng) will also be included in the shipment.

Viral Production & Use

• Packaging Plasmids: psPAX2 (plasmid #12260)
• Envelope: pMD2.G (plasmid #12259)
• Buffer: OptiPRO SFM
• Selectable Marker: None (Zeocin resistance is outside the LTRs and not transduced)

Biosafety

Requestor is responsible for compliance with their institution's biosafety regulations. Lentivirus is generally considered BSL-2. AAV is generally considered BSL-1, but may require BSL-2 handling depending on the insert. Biosafety Guide

Resource Information

• Terms and Licenses:
  • Terms of Use for Viral Vectors
• Industry Terms:
  • Not Available to Industry

Viral Quality Control

Titering Method:

• Proviral Integration Assay: Lenti-X 293T cells were serially transduced with 84478-LV or a control virus of known titer. 72 hours after transduction cells were harvested, and gDNA extracted and assessed for integrated copies of WPRE.

Notes:

• PCR confirmation of insert: PCR was carried out with primers targeting the dCas9 protein and WPRE. The PCR product was visualized on an agarose gel for size confirmation.
  • Forward Primer: dCas9-fwd, ACCGTGTACAACGAGCTGAC
  • Reverse Primer: WPRE-R, CATAGCGTAAAAGGAGCAACA
• Confirmation of protein expression: A549 cells were transduced with 84478-LV. 96 hours later, cells were fixed in 4% paraformaledyhyde and stained with 5 μg/mL anti-CRISPR Cas9 [7A9-3A3] (Abcam ab191468) primary antibody and Alexa Fluor 488 donkey anti-mouse IgG secondary antibody (ThermoFisher R37114). Nuclei were counterstained with DAPI. Cas9 expression was confirmed by fluorescence microscopy.

Visit our viral production page for more information.

Information for Concentrated Lentiviral Prep (Catalog # 84478-LVC)

Item is discontinued.

Addgene no longer distributes this item. Contact for more information.

This item has been discontinued.

Purpose

Ready-to-use Concentrated Lentiviral Prep particles produced from Fuw-dCas9-Dnmt3a_IM (#84478). In addition to the viral particles, you will also receive purified Fuw-dCas9-Dnmt3a_IM plasmid DNA.

Lentiviral particles carrying dCas9 fused with an inactive Dnmt3a catalytic domain (E664A, E756A)

Delivery

• Volume: .
• Titer: ≥5×10⁷ TU/mL
• Pricing: $150 USD for preparation of . virus + $30 USD for plasmid.
• Storage: Store at -80℃. Thaw just before use and keep on ice.
• Shipment: Viral particles are shipped frozen on dry ice. Plasmid DNA (≥ 200ng) will also be included in the shipment.

Viral Production & Use

• Packaging Plasmids: psPAX2 (plasmid #12260)
• Envelope: pMD2.G (plasmid #12259)
• Buffer: PBS
• Selectable Marker: None (Zeocin resistance is outside the LTRs and not transduced)
• Purification: Lentivirus was concentrated by precipitation in polyethylene glycol (PEG) followed by centrifugation.

Biosafety

Requestor is responsible for compliance with their institution's biosafety regulations. Lentivirus is generally considered BSL-2. AAV is generally considered BSL-1, but may require BSL-2 handling depending on the insert. Biosafety Guide

Resource Information

• Terms and Licenses:
  • Terms of Use for Viral Vectors
• Industry Terms:
  • Not Available to Industry

Viral Quality Control

Titering Method:

• Proviral Integration Assay: Lenti-X 293T cells were serially transduced with 84478-LVC or a control virus of known titer. 72 hours after transduction cells were harvested, and gDNA extracted and assessed for integrated copies of WPRE.

Notes:

• Quality control was performed on this lentiviral preparation prior to concentration. Results and explanations of quality control methods can be seen in the Information for Lentiviral Prep section on this page.

Visit our viral production page for more information.
