cyto-CFP-FRBx5
(Plasmid #103776)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 103776 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pECFP-C1
  • Backbone manufacturer
    Clontech
  • Backbone size w/o insert (bp) 4700
  • Total vector size (bp) 6367
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    cyto-CFP-FRBx5
  • Species
    Synthetic
  • Promoter CMV
  • Tag / Fusion Protein
    • ECFP

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NheI (not destroyed)
  • 3′ cloning site AgeI (not destroyed)
  • 5′ sequencing primer GGAGGTCTATATAAGCAGAGC
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    cyto-CFP-FRBx5 was a gift from Takanari Inoue (Addgene plasmid # 103776 ; http://n2t.net/addgene:103776 ; RRID:Addgene_103776)
  • For your References section:

    Intracellular production of hydrogels and synthetic RNA granules by multivalent molecular interactions. Nakamura H, Lee AA, Afshar AS, Watanabe S, Rho E, Razavi S, Suarez A, Lin YC, Tanigawa M, Huang B, DeRose R, Bobb D, Hong W, Gabelli SB, Goutsias J, Inoue T. Nat Mater. 2017 Nov 6. pii: nmat5006. doi: 10.1038/nmat5006. 10.1038/nmat5006 PubMed 29115293
