(Plasmid #105348)


Item Catalog # Description Quantity Price (USD)
Plasmid 105348 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
    pBRM-derivate (Szczesny et al., 2010)
  • Vector type
    Bacterial secretion
  • Selectable markers

Growth in Bacteria

  • Bacterial Resistance(s)
    Chloramphenicol and Gentamicin, 25 & 10 μg/mL
  • Growth Temperature
  • Growth Strain(s)
    ccdB Survival
  • Copy number
    Low Copy


  • Gene/Insert name
    secretion signal, ccdB cassette
  • Species
  • Mutation
    BsaI restriction sites removed

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BsaI (destroyed during cloning)
  • 3′ cloning site EcoRI (destroyed during cloning)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pCK016 was a gift from Johannes Stuttmann (Addgene plasmid # 105348 ; ; RRID:Addgene_105348)
  • For your References section:

    Peripheral infrastructure vectors and an extended set of plant parts for the Modular Cloning system. Gantner J, Ordon J, Ilse T, Kretschmer C, Gruetzner R, Lofke C, Dagdas Y, Burstenbinder K, Marillonnet S, Stuttmann J. PLoS One. 2018 May 30;13(5):e0197185. doi: 10.1371/journal.pone.0197185. eCollection 2018. 10.1371/journal.pone.0197185 PubMed 29847550
