BMR1_03g00790-bio-His
(Plasmid #108023)

• Purpose: Expresses enzymatically monobiotinylated full-length BMR1_03g00790 ectodomain with no N-linked glycans upon cotransfection with BirA in mammalian cells. Contains a C-terminal rat Cd4 d3+4 tag.
• Depositing Lab: Gavin Wright
• Depositing Organization: Wellcome Sanger Institute
  Located in United Kingdom of Great Britain and Northern Ireland
• Publication: Elton et al Int J Parasitol. 2019 Feb;49(2):115-125. doi: 10.1016/j.ijpara.2018.10.003. Epub 2018 Oct 24.

Backbone

• Vector backbone: pTT3
• Backbone manufacturer: Yves Durocher
• Backbone size w/o insert (bp): 6670
• Modifications to backbone: Addition of CD4, biotinylation sequence, 6xhis tags
• Vector type: Mammalian Expression

Growth in Bacteria

• Bacterial Resistance(s): Ampicillin, 100 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): DH5alpha
• Copy number: High Copy

Gene/Insert

• Gene/Insert name: BMR1_03g00790
• Species: B. microti
• Insert Size (bp): 843
• Mutation: all potential N-linked glycosylation sites (N-X-S/T, where X is not proline) were systematically removed by substituting alanine for serine/threonine at these sites.
• Promoter: CMV
• Tag / Fusion Protein:
  • ratCD4d3+4,biotinylation sequence, 6xHis (C terminal on backbone)

Cloning Information

• Cloning method: Restriction Enzyme
• 5′ cloning site: NotI (not destroyed)
• 3′ cloning site: AscI (not destroyed)
• 5′ sequencing primer: CMV-F
• 3′ sequencing primer: EBVori-F (5'-CCACTCAGTGTTGGCAAATG-3')

Resource Information

• A portion of this plasmid was derived from a plasmid made by: Made by gene synthesis. pTT3 was obtained from Yves Durocher, National Research Council of Canada

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry

DNA (Catalog # 108023-D50)

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

• Amount: 50 μg
• Concentration: 1 μg/μL
• Pricing: $495 USD
• Storage: 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

DNA (Catalog # 108023-D100)

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

• Amount: 100 μg
• Concentration: 1 μg/μL
• Pricing: $585 USD
• Storage: 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.
