gRNAs[bTub+Sxl].1046B
(Plasmid #112692)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 112692 Standard format: Plasmid sent in bacteria as agar stab 1 $94
Add to Cart
DNA 112692-D50 50 μg of DNA in Tris buffer $495
Add to Cart
DNA 112692-D100 100 μg of DNA in Tris buffer $585
Add to Cart

Backbone

  • Vector backbone
    white+attB
  • Vector type
    CRISPR
  • Selectable markers
    mini-white

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    U6.3-gRNA[bTub] and U6.3-gRNA[Sxl]
  • gRNA/shRNA sequence
    CCTGAGTGTGCATCAGCTGG and GATTGTCAACTACTTGCCCC
  • Species
    D. melanogaster (fly)
  • Entrez Gene
    Sxl (a.k.a. Dmel_CG43770, CG14425, CG18350, CG33070, CG43770, Dm-Sxl, DmSxl, Dmel\CG43770, Dmel_CG14425, Dmel_CG18350, Fl, Mex156, ORF2, SXL, Su(da), Sx1, SxL, Sxl-1 Sxl-2, Sxl-Pe, SxlPe, SxlPm, dSXL, fs(1)K1274, fs(1)M106, l(1)6Fa, melSxl, sxl)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Trademarks:

  • Zeocin® is an InvivoGen trademark.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 50 μg
  • Concentration 1 μg/μL
  • Pricing $495 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 100 μg
  • Concentration 1 μg/μL
  • Pricing $585 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    gRNAs[bTub+Sxl].1046B was a gift from Omar Akbari (Addgene plasmid # 112692 ; http://n2t.net/addgene:112692 ; RRID:Addgene_112692)

  • For your References section:

    Transforming insect population control with precision guided sterile males with demonstration in flies. Kandul NP, Liu J, Sanchez C HM, Wu SL, Marshall JM, Akbari OS. Nat Commun. 2019 Jan 8;10(1):84. doi: 10.1038/s41467-018-07964-7. 10.1038/s41467-018-07964-7 PubMed 30622266
