(Plasmid #118614)


Item Catalog # Description Quantity Price (USD)
Plasmid 118614 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone size w/o insert (bp) 9025
  • Total vector size (bp) 11725
  • Vector type
    Mammalian Expression, Lentiviral

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
  • Growth Strain(s)
    NEB Stable
  • Copy number


  • Gene/Insert name
  • Species
    M. musculus (mouse)
  • Insert Size (bp)
  • GenBank ID
    NM_009861 NM_009861
  • Entrez Gene
  • Promoter tetON CMV
  • Tag / Fusion Protein
    • mCherry (N terminal on insert)

Cloning Information

  • Cloning method Ligation Independent Cloning
  • 5′ sequencing primer ACTTGTGGCCGTTTACGTCG
  • 3′ sequencing primer gatctcaaatccctcggaagc
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pMCh1750_S2F-IMCg_doxy-CMV_mChe-Cdc42E7 was a gift from Marina Chekulaeva (Addgene plasmid # 118614 ; ; RRID:Addgene_118614)
  • For your References section:

    Alternative 3' UTRs direct localization of functionally diverse protein isoforms in neuronal compartments. Ciolli Mattioli C, Rom A, Franke V, Imami K, Arrey G, Terne M, Woehler A, Akalin A, Ulitsky I, Chekulaeva M. Nucleic Acids Res. 2018 Dec 22. pii: 5258023. doi: 10.1093/nar/gky1270. 10.1093/nar/gky1270 PubMed 30590745
