S10A mutant of H3S10ph biosensor
(Plasmid #120810)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 120810 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pcDNA3.1
  • Backbone manufacturer
    Invitrogen
  • Backbone size w/o insert (bp) 5368
  • Total vector size (bp) 7786
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Mouse histone H3-CFP-FHA2-histone H3 peptide (1-14aa) S10A-YFP
  • Species
    M. musculus (mouse), Synthetic
  • Insert Size (bp)
    2418
  • Mutation
    Serine 10 is mutated to Alanine, and Threonine 3, Threonine 6, and Threonine 11 are mutated to Alanine on histone H3 peptide (1-14aa)
  • Promoter CMV

Cloning Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    S10A mutant of H3S10ph biosensor was a gift from Yingxiao Wang (Addgene plasmid # 120810 ; http://n2t.net/addgene:120810 ; RRID:Addgene_120810)
  • For your References section:

    Coordinated histone modifications and chromatin reorganization in a single cell revealed by FRET biosensors. Peng Q, Lu S, Shi Y, Pan Y, Limsakul P, Chernov AV, Qiu J, Chai X, Shi Y, Wang P, Ji Y, Li YJ, Strongin AY, Verkhusha VV, Izpisua Belmonte JC, Ren B, Wang Y, Chien S, Wang Y. Proc Natl Acad Sci U S A. 2018 Nov 26. pii: 1811818115. doi: 10.1073/pnas.1811818115. 10.1073/pnas.1811818115 PubMed 30478057
