pcDNA3.1+ Flag-RAGB99L
(Plasmid #128101)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 128101 Standard format: Plasmid sent in bacteria as agar stab 1 $94
Add to Cart
DNA 128101-D50 50 μg of DNA in Tris buffer $495
Add to Cart
DNA 128101-D100 100 μg of DNA in Tris buffer $585
Add to Cart

Backbone

  • Vector backbone
    pcDNA3.1+
  • Backbone manufacturer
    invitrogen
  • Backbone size w/o insert (bp) 5359
  • Total vector size (bp) 6468
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Growth instructions
    The depositing lab used the strain Top10 in their studies.
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    Ras related GTP binding B
  • Alt name
    RAGB
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1109
  • Mutation
    Q99L (CAA to CTA)
  • GenBank ID
    NM_006064
  • Entrez Gene
    RRAGB (a.k.a. RAGB, bA465E19.1)
  • Promoter CMV
  • Tag / Fusion Protein
    • Flag (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NheI (not destroyed)
  • 3′ cloning site EcoRV (not destroyed)
  • 5′ sequencing primer CMV-F (CGCAAATGGGCGGTAGGCGTG)
  • 3′ sequencing primer BGH-Rev (TAGAAGGCACAGTCGAGG)
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    Flag pLJM1 RagB 99L (David Sabatini, Addgene plasmid #19315) and pcDNA3.1+ (invitrogen)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Trademarks:

  • Zeocin® is an InvivoGen trademark.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 50 μg
  • Concentration 1 μg/μL
  • Pricing $495 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 100 μg
  • Concentration 1 μg/μL
  • Pricing $585 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pcDNA3.1+ Flag-RAGB99L was a gift from Chi Van Dang (Addgene plasmid # 128101 ; http://n2t.net/addgene:128101 ; RRID:Addgene_128101)

  • For your References section:

    Acid Suspends the Circadian Clock in Hypoxia through Inhibition of mTOR. Walton ZE, Patel CH, Brooks RC, Yu Y, Ibrahim-Hashim A, Riddle M, Porcu A, Jiang T, Ecker BL, Tameire F, Koumenis C, Weeraratna AT, Welsh DK, Gillies R, Alwine JC, Zhang L, Powell JD, Dang CV. Cell. 2018 Jun 28;174(1):72-87.e32. doi: 10.1016/j.cell.2018.05.009. Epub 2018 May 31. 10.1016/j.cell.2018.05.009 PubMed 29861175
