(Plasmid #128943)


Item Catalog # Description Quantity Price (USD)
Plasmid 128943 Standard format: Plasmid sent in bacteria as agar stab 1 $75

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone size w/o insert (bp) 5566
  • Total vector size (bp) 7719
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
  • Growth Temperature
  • Growth Strain(s)
  • Growth instructions
    protein expression in C43(DE3) strains
  • Copy number


  • Gene/Insert name
    ferric enterobactin receptor
  • Alt name
  • Alt name
  • Species
    Pseudomonas aeruginosa PAO1
  • Insert Size (bp)
  • Mutation
    Signal peptide sequence has been removed (1-75)
  • GenBank ID
  • Promoter T7
  • Tags / Fusion Proteins
    • TEV protease cleavable 7xHis (N terminal on backbone)
    • TamA (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NcoI (not destroyed)
  • 3′ cloning site BamHI (not destroyed)
  • 5′ sequencing primer T7 promoter
  • 3′ sequencing primer T7 terminator
  • (Common Sequencing Primers)

Resource Information

  • Terms and Licenses
  • Industry Terms
    • Not Available to Industry

Depositor Comments

pTAMAHISTEV vector has been obtained by replacing pelB signal peptide of pEPELBHISTEV (courtesy of Dr. Huanting Liu, University St Andrews) by tamA signal peptide

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pTAMAHISTEV_PfeA was a gift from James Naismith (Addgene plasmid # 128943 ; ; RRID:Addgene_128943)
  • For your References section:

    The complex of ferric-enterobactin with its transporter from Pseudomonas aeruginosa suggests a two-site model. Moynie L, Milenkovic S, Mislin GLA, Gasser V, Malloci G, Baco E, McCaughan RP, Page MGP, Schalk IJ, Ceccarelli M, Naismith JH. Nat Commun. 2019 Aug 14;10(1):3673. doi: 10.1038/s41467-019-11508-y. 10.1038/s41467-019-11508-y PubMed 31413254
