PurposeYellow protein calcium sensor expressed under human Synapsin1 promoter, for AAV production or direct transfection, slow variant
|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||135424||Standard format: Plasmid sent in bacteria as agar stab||1||$75|
|AAV1||135424-AAV1||Virus (100 µL at titer ≥ 7×10¹² vg/mL) and Plasmid.|
This material is available to academics and nonprofits only.
Vector typeMammalian Expression, AAV
Growth in Bacteria
Bacterial Resistance(s)Ampicillin, 100 μg/mL
Growth Strain(s)NEB Stable
Copy numberHigh Copy
- Promoter hSyn
- Cloning method Gibson Cloning
- 5′ sequencing primer actagtCTCGAGGATATCgccac
- 3′ sequencing primer tcgatAAGCTTGATATCTTTGTACACCTTACTT (Common Sequencing Primers)
Terms and Licenses
- Not Available to Industry
- Zeocin® is an InvivoGen trademark.
Information for AAV1 (Catalog # 135424-AAV1) ( Back to top )
Ready-to-use AAV1 particles produced from pAAV-syn-jYCaMP1s (#135424). In addition to the viral particles, you will also receive purified pAAV-syn-jYCaMP1s plasmid DNA.Synapsin-driven expression of calcium sensor YCaMP1s. These AAV preparations are suitable purity for injection into animals.
- Volume 100 µL
- Titer ≥ 7×10¹² vg/mL
- Pricing $350 USD for preparation of 100 µL virus + $30 USD for plasmid.
- Storage Store at -80℃. Thaw just before use and keep on ice.
- Shipment Viral particles are shipped frozen on dry ice. Plasmid DNA (≥ 200ng) will also be included in the shipment.
Viral Production & Use
- Packaging Plasmids encode adenoviral helper sequences and AAV rep gene, AAV1 cap gene
- Buffer PBS + 0.001% Pluronic F-68 + 200 mM NaCl
- Serotype AAV1
- Purification Iodixanol gradient ultracentrifugation
Requestor is responsible for compliance with their institution's biosafety regulations. Lentivirus is generally considered BSL-2. AAV is generally considered BSL-1, but may require BSL-2 handling depending on the insert. Biosafety Guide
Viral Quality Control
- Addgene ensures high quality viral vectors by optimizing and standardizing production protocols and performing rigorous quality control (QC) (see a list of our QC assays). The specific QC assays performed varies for each viral lot. To learn which specific QC assays were performed on your lot, please contact us.
- Titer: the exact titer of your sample will be reported on the tube. The titer you see listed on this page is the guaranteed minimum titer. See how titers are measured.
Visit our viral production page for more information.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:pAAV-syn-jYCaMP1s was a gift from Kaspar Podgorski (Addgene plasmid # 135424 ; http://n2t.net/addgene:135424 ; RRID:Addgene_135424)
For viral preps, please replace (Addgene plasmid # 135424) in the above sentence with: (Addgene viral prep # 135424-AAV1)
For your References section:jYCaMP: an optimized calcium indicator for two-photon imaging at fiber laser wavelengths. Mohr MA, Bushey D, Aggarwal A, Marvin JS, Kim JJ, Marquez EJ, Liang Y, Patel R, Macklin JJ, Lee CY, Tsang A, Tsegaye G, Ahrens AM, Chen JL, Kim DS, Wong AM, Looger LL, Schreiter ER, Podgorski K. Nat Methods. 2020 May 25. pii: 10.1038/s41592-020-0835-7. doi: 10.1038/s41592-020-0835-7. 10.1038/s41592-020-0835-7 PubMed 32451475
