pTJK637
(Plasmid #138010)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 138010 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    PX459
  • Vector type
    Mammalian Expression, CRISPR
  • Selectable markers
    Puromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable ; Stellar Cells
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    GATA1 sgRNA
  • gRNA/shRNA sequence
    GCTGGGCCTACGGCAAGACG
  • Species
    H. sapiens (human)
  • Mutation
    None
  • Entrez Gene
    GATA1 (a.k.a. ERYF1, GATA-1, GF-1, GF1, HAEADA, NF-E1, NFE1, XLANP, XLTDA, XLTT)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site Bbs1 (unknown if destroyed)
  • 3′ cloning site Bbs1 (unknown if destroyed)
  • 5′ sequencing primer GAGGGCCTATTTCCCATGATT
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pTJK637 was a gift from Tami Kingsbury (Addgene plasmid # 138010 ; http://n2t.net/addgene:138010 ; RRID:Addgene_138010)
