pcDNA3.1 Hmga2 tr
(Plasmid #14793)

• Depositing Lab: David Bartel
• Depositing Organization: Whitehead Institute for Biomedical Research
  Located in United States of America
• Publication: Mayr et al Science. 2007 Mar 16. 315(5818):1576-9.

Backbone

• Vector backbone: pcDNA3.1
• Backbone manufacturer: Invitrogen
• Backbone size w/o insert (bp): 5500
• Vector type: Mammalian Expression
• Selectable markers: Neomycin (select with G418)

Growth in Bacteria

• Bacterial Resistance(s): Ampicillin, 100 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): DH5alpha
• Copy number: High Copy

Gene/Insert

• Gene/Insert name: Hmga2 truncated
• Alt name: HMGA2
• Species: M. musculus (mouse)
• Insert Size (bp): 900
• Mutation: truncataed HMGA2. As in human tumors, Hmga2-tr lacks the spacer, the acidic domain, and the entire 3' UTR with its miRNA complementary sites. (see article and author's map for details)
• GenBank ID: BC052158
• Entrez Gene: Hmga2 (a.k.a. 9430083A20Rik, HMGI-C, Hmgic, pg, pygmy)

Cloning Information

• Cloning method: Restriction Enzyme
• 5′ cloning site: EcoRI (not destroyed)
• 3′ cloning site: EcoRI (not destroyed)
• 5′ sequencing primer: T7

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry

Depositor Comments

The 3' UTR of the mouse Hmga2 cDNA (BC052158) was subcloned into pCR2.1-TOPO (Invitrogen) for site-directed mutagenesis. To disrupt each let-7 complementary site, the nucleotides that paired to nucleotides 3 and 5 of the miRNA were substituted (see Author's map), using the Quikchange site-directed mutagenesis kit (Stratagene). The UTR fragment was then cloned back into the vector containing the Hmga2 cDNA (pCMV•SPORT6.1). To construct the mammalian expression vectors, Hmga2 inserts were excised from the pCMV•SPORT6.1 constructs using EcoRI restriction sites and cloned into pcDNA3.1 (Invitrogen).

DNA (Catalog # 14793-D50)

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

• Amount: 50 μg
• Concentration: 1 μg/μL
• Pricing: $495 USD
• Storage: 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

DNA (Catalog # 14793-D100)

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

• Amount: 100 μg
• Concentration: 1 μg/μL
• Pricing: $585 USD
• Storage: 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.
